XCMG single drum road roller XS223J
Main specifications:
|
Item |
Unit |
Data |
|
XS223J |
||
| weight/Dimensions | ||
| Max. Operating weight |
kg |
22000 |
| Front wheel weight |
kg |
11000 |
| Rear wheel weight |
kg |
11000 |
| line pressure |
N/cm |
516 |
| Vibration frequency |
Hz |
28/33 |
| Theoretical amplitude (high/low) |
mm |
1.86/0.93 |
| Centrifugal force(High/Low) |
kN |
374/290 |
| Speed range | ||
| Forward-I |
km/h |
2.95 |
| Forward-II |
km/h |
5.78 |
| Forward-III |
km/h |
9.4 |
| Wheelbase |
mm |
3180 |
| Vibration wheel width |
mm |
2130 |
| Gradeability |
30% |
|
| Min. turning radius |
mm |
6500 |
| Vibration wheel diameter |
mm |
1600 |
| Min. ground clearance |
mm |
448 |
| Overall dimensions |
mm |
6220*2430*3200 |
| Engine | ||
| model |
SC8DK185.2G3 |
|
| rated turning speed |
r/min |
1800 |
| Output |
kW |
136 |
| Specifications | ||
| Vibration pressure |
Mpa |
35 |
| Steering pressure |
Mpa |
16 |
